Specifications :

80PLUS
- Platinum

Cybenetics Efficiency Level
- Titanium

Cybenetics Noise Level
- A-

Form Factor
- ATX/EPS

Dimensions
- 210 × 150 × 86 mm

Fan Information
- Fan Size : 135 mm
- Fan Control : Digital Hybrid Fan Control
- Fan Bearing : Fluid Dynamic Bearing
- Life Expectancy : 50,000 hours at 40 °C, 15 % - 65 % RH


Cable Information
- Modularity : Fully Modular
- Cable type : Individual Black Cables with Braided Pattern

Electrical Features
- Operating Temperature :0 - 50 °C
- MTBF @ 25 °C, excl. fan :100,000 hours
- AC Input : Full Range
- Protection : OPP, OVP, UVP, OCP, OTP, SCP

Safety and Environmental
- Safety and EMC : cTUVus, TUV, CB, CCC, BSMI, EAC, CE
- Environmental Compliance : Energy Star, RoHS, WEEE, ErP Lot 6, REACH

Warranty
- 12 Years

Power Output
AC Input
- 100 V - 240 V
- 15 - 10 A
- 50 Hz - 60 Hz

Cables
- MB (24/20 pins) : 1
- CPU (8/4 pins) : 3
- PCIe (8/6 pins) : 6
- SATA : 4
- SATA 3.3 V : 1
- Molex : 1
- 12V-2x6 (12+4 Pins to 12+4 Pins) : 2
