Specifications
Packet Buffer Size N/A
FAN No
Comply with RoHS 6 Yes
Energy Efficiency Ethernet EEE Yes
Power Saving By Link Status Yes (suggest to remove this feature)
Power Saving By Cable Length Yes (suggest to remove this feature)
Jumbo Frame 9216 Bytes
Number of Queues 8
Store Forwarding Yes
Dimension 100 x 64 x 24 mm
Weight 0.16kgs
Operation Temperature 0 ~ 40 °C
Storage Temperature - 10 ~ 65 °C
Operation Humidity 0% ~ 95% RH
Storage Humidity 0% ~ 95% RH
Maximum Power Consumption 3.55W
Standby Power Consumption 0.79W
Maximum Heat Dissipation 12.11 BTU/h
MTBF 1,455,562 hours
Power Input 5V DC
8023x Flow Control Yes
MAC Address Table Size 4K
1000Base-T Interface Yes
Auto MDIMDIX Yes
Switching Capacity 10Gbps
Max Packet Forwarding Rate 7.44 Mpps
