𝗦𝗽𝗲𝗰𝗶𝗳𝗶𝗰𝗮𝘁𝗶𝗼𝗻𝘀 :

80PLUS®
- Gold

Cybenetics Efficiency Level
- Platinum (See report)

Cybenetics Noise Level
- Lambda A (See report)

Form Factor
- Intel ATX 12 V

Dimensions
- 160 mm (L) x 150 mm (W) x 86 mm (H)

Voltage
- 100 V - 240 V

Current
- 13 - 6.5 A

Frequency
- 50 Hz - 60 Hz

Fan Information
- Fan Size : 135 mm
- Fan Control : Digital Fan Control
- Fan Bearing : Fluid Dynamic Bearing
- Life Expectancy : 50,000 hours at 40 °C, 15 % - 65 % RH

Cable Information
- Modularity : Fully Modular
- Cable type : Flat black cables

Electrical Features
- Operating Temperature : 0 - 50 °C (derating from 100 % to 80 % from 40 °C to 50 °C)
- MTBF @ 25 °C, excl. fan :150,000 hours
- AC Input : Full Range
- Protection : OPP, OVP, UVP, OCP, OTP, SCP

Safety and Environmental
- Safety and EMC : cTUVus, TUV, CB, CCC, BSMI, EAC, CE
- Environmental Compliance : Energy Star, RoHS, WEEE, ErP Lot 6, REACH

Warranty
- 10 Years

CABLES
- MB (24/20 pins) : 1
- CPU (8/4 pins) : 2
- PCIe (8/6 pins) : 3
- SATA : 16
- SATA 3.3 : 2
- Molex : 3
- 12VHPWR : 1
