MODULAR : Full Modular
MODEL : RS-A00-AFBA-G1
PFC : Active PFC (>0.9 typical)
ATX VERSION : Intel Form Factor ATX 12V V2.31
DIMENSIONS (L X W X H) : 150 x 170 x 86 mm / 5.9 x 6.7 x 3.4 inch
INPUT VOLTAGE : 90-264Vac (Auto Range)
INPUT CURRENT : 12-6A
INPUT FREQUENCY : 60-50Hz
POWER GOOD SIGNAL : 100 - 500 ms
HOLD UP TIME : >17ms
EFFICIENCY : 90% Typically
MTBF : >100,000 Hours
PROTECTIONS : OVP, UVP, OPP, OTP, SCP
OUTPUT CAPACITY : 1000W
OPERATING TEMPERATURE : 0-40°C
REGULATORY : CE, TUV, TUV-SUDNRTL, FCC, GOST, CCC, BSMI, C-tick, KCC
FAN SIZE : Silent FDB 135mm
CERTIFICATION : 80 Plus Gold
MB 20+4 PIN CONNECTORS : 1
CPU 12V 4+4 PIN CONNECTORS : 2
PCI-E 6+2 PIN CONNECTORS : 8
SATA CONNECTORS : 9
PERIPHERAL 4-PIN CONNECTORS : 4
FDD CABLE 4-PIN CONNECTORS : 1
PRODUCT NAME : V1000
WATTAGE : Above 750W
80 PLUS : Gold
SERIES : V Gold Series
