SPESIFIKASI:
● Usable Capacities : 500GB/ 1TB/ 2TB/ 4TB
● NAND Components : 3D NAND Flash Memory
● Interface : PCIe Gen4x 4
● Form Factor : M.2 2280
● Package Dimensions (L×W×H) : 123 x 85 x 4.3 mm
● Product Dimensions (L×W×H) : 22 x 80 x 4 mm (Max)
● Weight : 6.6g
● Max Sequential Read* :
>>> 500GB: Up to 4,700MB/s
>>> 1TB: Up to 5,100MB/s
>>> 2TB, 4TB: Up to 5,000MB/s
● Max Sequential Write* :
>>> 500GB: Up to 1,700MB/s
>>> 1TB: Up to 3,200MB/s
>>> 2TB, 4TB: Up to 4,200MB/s
● TBW : 500G: 160, 1TB: 320, 2TB: 640, 4TB: 900
● PCIe Link Power Management : PS0/ PS1/ PS2/ PS3/ PS4, APST, ASPM, L1.2
● Operating Temperature :
● Storage Temperature : -40°C to 85°C
● Certifications : BSMI, CE, FCC, KCC, REACH, RoHS, VCCI
● MTBF : 1,500,000 Hours
● Error Correction Code : LDPC (Low Density Parity Check) ECC Algorithm
● Product Health Monitoring : Self-Monitoring, Analysis and Reporting Technology (S.M.A.R.T)
● Full End-to-End Data path protection : Supported
● Performance Optimization : TRIM (requires OS support)
● Warranty : 5-Year Limited Warranty or TBW*
