Model Name: SPATIUM M480 PCIe 4.0 NVMe M.2
Capacity: 2TB
Controller: PHISON E18
Flash Memory: 3D NAND
DRAM Cache: 2GB DDR4
Form Factor: M.2 2280
Interface PCIe: Gen4x4, NVMe 1.4
Compatibility: PCIe Gen4 / Gen3 / Gen2 / Gen1
Dimensions: 80.00mm (L) x 22.00mm (W) x 2.15mm (H)
Sequential Read up to (MB/s): 7000
Sequential Write up to (MB/s): 6800
Random Read 4KB up to(IOPS): 650,000
Random Write 4KB up to (IOPS): 700,000
Maximum Operating Power (W): 8.2
Idle Power PS3 (mW): 22
Low Power L1.2 (mW): 3
Operating Temperatures: 0°C – 70°C
Storage Temperatures: -40°C – 85°C
Terabytes Written (TBW): 1400
Mean Time Between Failure (MTBF): Up to 1,600,000 Hours
Limited Warranty: 5 Years, or the coverage for the maximum
TBW as stated, whichever comes first.
Advanced Features:
TRIM (Performance Optimization, OS support
required)
SMART (Self-Monitoring, Analysis and
Reporting Technology)
LDPC (Low Density Parity Check) ECC
Algorithm
End to End Data Path Protection
APST (Autonomous Power State Transition)
AES256/TCG OPAL2.0/Pyrite (Encryption,
Data Security)
