Sodimm DDR5 8GB Kingston Fury Beast KF548S38IB-8 4800MT/s CL38 / Sodim DDR5 8GB
--------------------
KF548S38IB-8
8GB 1G x 64-Bit
DDR5-4800 CL38 262-Pin SODIMM

Spesifikasi :
CL(IDD) : 38 cycles
Row Cycle Time (tRCmin) : 48ns(min.)
Refresh to Active/Refresh Command Time (tRFCmin) : 295ns(min.)
Row Active Time (tRASmin) : 29.12ns(min.)
UL Rating : 94 V - 0
Operating Temperature : 0 C to +85C
Storage Temperature : 55o C to +100C


DESCRIPTION :
FURY KF548S38IB-8 is a 1G x 64-bit (8GB) DDR5-4800 CL38
SDRAM (Synchronous DRAM) 1Rx16, memory module, based on
four 1G x 16-bit FBGA components per module. The module
supports Intel Extreme Memory Profiles (Intel XMP) 3.0.
Each module has been tested to run at DDR5-4800 at a low latency
timing of 38-38-38 at 1.1V. Additional timing parameters are shown
in the Plug-N-Play (PnP) Timing Parameters section below. Each
262-pin DIMM uses gold contact fingers. The JEDEC
standard electrical and mechanical specifications are as

FEATURES :
Power Supply: VDD = 1.1V Typical
VDDQ = 1.1V Typical
VPP = 1.8V Typical
VDDSPD = 1.8V to 2.0V
On-Die ECC
Height 1.18 (30mm)
