Main Chip Sets
- CPU : GX 6701, 32bit CK610M CPU with MMU , provides up to 1500 DMIPS Support Boot from SPI NOR flash，SPI NAND flash
- SDRAM : Embedded16 bit width, 64MB DDR2 SDRAM
- Polarization : 22KHz±0.4KHz(0.6V±0.2V)tone, Overload Protection
- Loop-Through : YES
- Tuner Type : R836

DVB-T/T2 Tuner
- Frequency Range : "VHF174~230MHz UHF 470~862MHz"
- Input Impedance : 75Ω
- Input Level Range : Min -78dbm max -20dbm（64QAM,8K 1/8,7/8）
- Video Decode : MPEG-2 ISO/IEC 13818-2 MP@ML, H.264(MPEG4 part 10) main and high profile level 4.1/MPEG-2 MP@HL
HDMI transmitter output delivers an HD video (1080p, 1080i, 720p, 576p, 480p, etc)
Encoding of Teletext, close caption, WSS, CGMS and VPS

Video Decoder
- Aspect Ratio : 4:3、16:9
- Video Resolution : 1920×1080,1280×720,720×480
- Audio Decode : "MPEG-1 layerI/II，PCM down mix，IEC958 SPDIF，
Sampling rates of 32kHz, 44.1kHz, 48kHz, and MPEG-2 half sampling rates of 16kHz, 22.05kHz, 24kHz supported

Audio Decode
- Sound Mode ; LEFT/RIGHT/STEREO/MONO
- Sampling Frequency : 32KHz 、44.1KHz 、48KHz
- Video Bandwidth : SD:5.0MHz(-3dB),HD:30MHz(-3dB)
- Video Impedance : 3dB) 75Ω
- Video Voltage Level : 1.0Vp-p

AV Output
- Audio Freq. Range : 20～20KHz
- Audio Impedance : 600Ω
- Audio Voltage Level : 2Vrms(5.6Vp-p)
- Input Voltage : AC 100～250V，50Hz/60Hz
- Consumption : Max 8W

Environment
- Standby : ＜1W 0
- Temperature : ～40℃
- Humidity : <95％

Terdapat Early Warning System yang dapat mendeteksi Gempa/tsunami
Include Kabel RCA Tinggal di install
