PRODUCT SPECIFICATIONS

Physical
Socket: Intel Socket 1700
Foundry: Intel
Process Size: 10 nm
Die Size: 257 mm²
Package: FC-LGA16A
tCaseMax: 72°C
tJMax: 100°C

Performance
Frequency: 3.5 GHz
Turbo Clock: up to 5.3 GHz
E-Core Frequency: 2.6 GHz up to 4 GHz
Base Clock: 100 MHz
Multiplier: 35.0x
Multiplier Unlocked: Yes
TDP: 125 W
PL1: 181 W
PL2: 181 W
PL2 Tau Limit: Unlimited

Architecture
Codename: Raptor Lake-R
Generation: Core i5 (Raptor Lake Refresh)
Memory Support: DDR4, DDR5
DDR4 Speed: 3200 MT/s
DDR5 Speed: 5600 MT/s
Memory Bus: Dual-channel
ECC Memory: Yes
PCI-Express: Gen 5, 16 Lanes (CPU only)
Secondary PCIe: Gen 4, 4 Lanes
Chipsets: Intel 600 Series, Intel 700 Series

Core Config
# of Cores: 14
# of Threads: 20
Hybrid Cores: P-Cores: 6
E-Cores: 8
SMP # CPUs: 1
Integrated Graphics: N/A

Cache
Cache L1: 80 KB (per core)
Cache L2: 2 MB (per core)
Cache L3: 24 MB (shared)
E-Core L1: 96 KB (per core)
E-Core L2: 4 MB (per module)
