Processors AMD RYZEN 7 9700X BOX 100-100001404WOF

Name : AMD Ryzen™ 7 9700X
Series : Ryzen 9000 Series
Market Segment : Enthusiast Desktop
Former Codename : Granite Ridge AM5
Architecture : Zen 5

# of CPU Cores : 8
Multithreading (SMT) : Yes
# of Threads : 16
Max. Boost Clock : Up to 5.5 GHz
Base Clock : 3.8 GHz
L1 Cache : 640 KB
L2 Cache : 8 MB
L3 Cache : 32 MB
Default TDP : 65W

Unlocked for Overclocking : Yes
AMD EXPO™ Memory Overclocking Technology : Yes
Precision Boost Overdrive : Yes
Curve Optimizer Voltage Offsets : Yes
AMD Ryzen™ Master Support : Yes

CPU Socket : AM5
Supporting Chipsets : A620 , X670E , X670 , B650E , B650 , X870E , X870
CPU Boost Technology : Precision Boost 2
Instruction Set : x86-64

Recommended Cooler : Premium air cooler recommended for optimal performance
Max. Operating Temperature (Tjmax) : 95°C

Native USB 3.2 Gen 2 (10Gbps) Ports : 4
Native USB 2.0 (480Mbps) Ports : 1
PCI Express® Version : PCIe® 5.0
Native PCIe® Lanes (Total/Usable) : 28 , 24
Additional Usable PCIe Lanes from Motherboard
X870E 8x Gen4
X870 4x Gen4
X670E 12x Gen4
X670 12x Gen4
B650E 8x Gen4
B650 8x Gen4
NVMe Support : Boot , RAID0 , RAID1 , RAID5 , RAID10
System Memory Type : DDR5
Memory Channels : 2
Max. Memory : 192 GB
System Memory Subtype : UDIMM
Max Memory Speed
2x1R DDR5-5600
2x2R DDR5-5600
4x1R DDR5-3600
4x2R DDR5-3600

Graphics Model : AMD Radeon™ Graphics
Graphics Core Count : 2
Graphics Frequency : 2200 MHz

Garansi Resmi 3 Tahun
