Product Specifications
PNY Part Number VCG4070S12TFXXPB1-O
UPC Code 751492786407
CUDA Cores 7168
Clock Speed 1980 MHz
Boost Speed 2505 MHz
Memory Speed (Gbps) 21
Memory Size 12GB GDDR6X
Memory Interface 192-bit
Memory Bandwidth (GB/sec) 504
TDP 220 W
NVLink Not Supported
Outputs DisplayPort 1.4a (x3), HDMI 2.1
Multi-Screen 4
Resolution 7680 x 4320 @120Hz (Digital)3
Power Input 16-pin (One 16-pin to Two 8-pin)
Bus Type PCI-Express 4.0 x16
Card Dimensions 12.01" x 4.7" x 1.57"; 2 Slot

KEY FEATURES
Powered by NVIDIA DLSS 3, ultra-efficient Ada Lovelace arch, and full ray tracing
Dedicated Ray Tracing Cores
Dedicated Tensor Cores
NVIDIA DLSS 3
Game Ready and NVIDIA Studio Drivers
NVIDIA® GeForce Experience™
NVIDIA Broadcast
NVIDIA G-SYNC®
NVIDIA GPU Boost™
PCI Express® Gen 4
Microsoft DirectX® 12 Ultimate
Vulkan RT APIs, Vulkan 1.3, OpenGL 4.6
HDCP 2.3
DisplayPort 1.4a, up to 4K at 240Hz or 8K at 60Hz with DSC, HDR
As specified in HDMI 2.1a: up to 4K 240Hz or 8K 60Hz with DSC, Gaming VRR, HDR
One 16-pin to Two 8-pin Power Cable Included

MINIMUM SYSTEM REQUIREMENTS
PCI Express-compliant motherboard with one dual-width x16 graphics slot
Two 8-pin supplementary power connectors
700 W or greater system power supply2
Microsoft Windows® 11 64-bit, Windows 10 (November 2018 or later) 64-bit, Linux 64-bit
Internet connection
