CPU
- Intel® Socket LGA1700 for 12th Gen Intel® Core™, Pentium® Gold and Celeron® Processors

Chipset
- Intel Z690

Memory
4 x DIMM, Max. 128GB, DDR5 6666(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6133(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5333(OC)/ 5200(OC)/ 5066(OC)/ 5000(OC)/ 4800(JEDEC) MHz

Graphics
- 1x HDMI 2.1 with HDR port, supports a maximum resolution of 4K 60Hz
- 1x DisplayPort 1.4 port with HBR3, supports a maximum resolution of 4K 60Hz
* Available only on processors featuring integrated graphics.Graphics specifications may vary depending on the CPU installed.

Expansion Slots
- 3x PCIe x16 slots
* PCI_E1 & PCI_E2 slots (From CPU), Support PCIe 5.0
* PCI_E3 slot (From Z690 Chipset), Supports PCIe 3.0 x4

Supports PCIe 3.0 x4
Storage
- 5x M.2 slots (Key M)
* M2_1 slot (From CPU), Supports PCIe 4.0 x4
* M2_2 slot (From Z690 Chipset), Supports PCIe 4.0 x4
* M2_3 slot (From Z690 Chipset), Supports PCIe 4.0 x4
* M2_4 slot (From Z690 Chipset), Supports PCIe 3.0 x4
* M2_5 slot (From Z690 Chipset), Supports PCIe 4.0 x4
- 4x SATA 6Gb/s ports - SATA5~8* (From Z690 Chipset)1
- 2 x SATA 6Gb/s ports - SATAA & SATAB (From ASMedia ASM1061)

Ethernet
- 1x Intel® I225-V 2.5Gbps LAN

Wireless LAN & BLUETOOTH®
- Intel® Wi-Fi 6
* The Wireless module is pre-installed in the M.2 (Key-E) slot
* Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz (160MHz) up to 2.4Gbps
* Supports 802.11 a/ b/ g/ n/ ac/ ax
* Supports Bluetooth® 5.2

Form Factor
- ATX
- 30.5cm x 24.4cm
