MSI MPG B550 Gaming Plus (AM4, AMD Promontory B550, DDR4, USB3.2, SATA3)
Brand : MSI
Model : MPG B550 Gaming Plus
CPU Type : Supports AM4 socket 3rd Gen AMD Ryzen processors, and future AMD Ryzen processors with BIOS update
Chipset : AMD B550
Memory Standard : 4 DDR4 DIMM, 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ Up to 4400+ Mhz
Maximum Memory Supported : Up to 128GB Dual channel
Expansion Slots : 1 PCIe 4.0/ 3.0 x16, 1 PCIe 3.0 x16, 2 PCIe 3.0 x1
SATA Port : 6 SATA 6Gb/s
M.2 : 2 M.2 slots (Key M)
Onboard Video Chipset : HDMI, DisplayPort (Available for the processor with integrated graphics)
Multi-GPU support : Supports 2-Way AMD CrossFire Technology
Audio Chipset : Realtek ALC892
LAN Chipset : Realtek 8111H
Rear Panel Ports : PS/2, DP, LAN Port, USB 3.2 Gen2, HD Audio Connectors, Flash BIOS Button, USB 2.0, HDMI, USB 2.0, USB 3.2 Gen1, USB 3.2 Gen2 (Type-C), Optical S/PDIF OUT
Form Factor : ATX (30.5 cm x 24.4 cm)
