CPU
- Intel® Socket LGA1700 for 12th Gen Intel® Core™, Pentium® Gold and Celeron® Processors

Chipset
- Intel Z690

Memory
4 x DIMM, Max. 128GB, DDR5 up to 6400+ MHz

Graphics
- 1x HDMI 2.1 with HDR port, supports a maximum resolution of 4K 60Hz
- 1x DisplayPort 1.4 port, supports a maximum resolution of 4K 60Hz
* Available only on processors featuring integrated graphics.Graphics specifications may vary depending on the CPU installed.

Expansion Slots
- 3x PCIe x16 slots
* PCI_E1 (from CPU), Supports up to PCIe 5.0 x16
* PCI_E3 (From Z690 chipset), Supports up to PCIe 3.0 x4
* PCI_E4 (From Z690 chipset), Support up to PCIe 3.0 x1
- 1x PCIe 3.0 x1 slot (from Z690 chipset)

Storage
- 4x M.2 slots (Key M)
* M2_1 slot (From CPU), Supports up to PCIe 4.0 x4
* M2_2 slot (From Z690 chipset), Supports up to PCIe 4.0 x4
* M2_3 slot (From Z690 chipset), Supports up to PCIe 3.0 x4
* M2_4 slot (From Z690 chipset), Supports up to PCIe 4.0 x4
- 6x SATA 6Gb/s ports (from Z690 chipset)

Ethernet
- 1x Intel® I225-V 2.5Gbps LAN

Wireless LAN & BLUETOOTH®
- Intel® Wi-Fi 6
* The Wireless module is pre-installed in the M.2 (Key-E) slot
* Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz (160MHz) up to 2.4Gbps
* Supports 802.11 a/ b/ g/ n/ ac/ ax
* Supports Bluetooth® 5.2

Form Factor
- ATX
- 30.5cm x 24.4cm
