CPU
- Intel® Socket LGA1700 for 12th Gen Intel® Core™, Pentium® Gold and Celeron® Processors

Chipset
- Intel B660

Memory
- 4 x DIMM, Max. 128GB, DDR4
3200/3000/2933/2666/2400/2133 MHz memory modules

Graphics
- 1x HDMI 2.1 with HDR port, supports a maximum resolution of 4K 60Hz
- 1x DisplayPort 1.4 port with HBR3, supports a maximum resolution of 4K 60Hz

Expansion Slots
- 2x PCIe x16 slots
* PCI_E1 slot (From CPU)
** Supports PCIe 4.0 x16
- PCI_E3 slot (From B660 Chipset)
* Supports PCIe 3.0 x4
- 1x PCIe 3.0 x1 slot

Storage
- 4x SATA 6Gb/s ports (SATA5~8, from B660 Chipset)1
- 2x SATA 6Gb/s ports (SATA_A & SATA_B, from ASMedia ASM1061)
- 2x M.2 slots (Key M)
* M2_1 slot (From CPU)
** Supports PCIe 4.0 x4
** Supports 2242/ 2260/ 2280 storage devices
* M2_2 slot (From B660 Chipset)1
** Supports PCIe 4.0 x4
** Supports SATA 6Gb/s
** Supports 2242/ 2260/ 2280 storage devices
** Supports Intel® Optane™ Memory

Ethernet
- 1x Realtek® 8125BG 2.5Gbps LAN controller

WIRELESS LAN & BLUETOOTH
- Intel® Wi-Fi 6
# The Wireless module is pre-installed in the M.2 (Key-E) slot
# Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ up to 2.4Gbps
# Supports 802.11 a/ b/ g/ n/ ac/ ax
# Supports Bluetooth® 5.2

Form Factor
- microATX
- 24.4cm x 24.4cm
