Size : 120x120x25 mm
Mounting hole spacing : 105x105 mm
Connector & pin-configuration : 4-pin PWM
Cable length : 1cm + 30cm NA-EC1 extension cable
Bearing : SSO2
Blade geometry : A-Series with Flow Acceleration Channels
Frame technology : AAO (Advanced Acoustic Optimisation)
Material Sterrox® : LCP
Rotational speed (+/- 10%) : 2000 RPM
Min. rotational speed (PWM, +/-20%) : 450 RPM
Airflow : 102,1 m³/h
Acoustical noise : 22,6 dB(A)
Static pressure : 2,34 mm H₂O
Max. input power : 1,68 W
Max. input current : 0,14 A
Operating voltage : 12 V
Voltage PWM signal : 5 V
MTTF : > 150.000 h
