MODEL : MPE-5001-ACABN
ATX VERSION : ATX 12V Ver. 2.41
PFC : Active PFC
INPUT VOLTAGE : 200-240Vac
INPUT CURRENT : 5A
INPUT FREQUENCY : 50-60Hz
DIMENSIONS (L X W X H) : 140 x 150 x 86 mm
FAN SIZE : 120mm
FAN BEARING : Sleeve Bearing
EFFICIENCY : 85% @ Typical Load
80 PLUS RATING : 80 PLUS Standard 230V EU
ERP 2014 LOT 3 : Yes
OPERATING TEMPERATURE : 40°C
POWER GOOD SIGNAL : 100 - 500 ms
HOLD UP TIME : >14ms at 100% load
MTBF : >100,000 Hours
PROTECTIONS : OVP, OPP, OTP, SCP, UVP
REGULATORY : TUV, cTUVus, CE, BSMI, FCC, EAC, RCM, KCC, CCC, CB
MB 24-PIN CONNECTORS : 1
EPS 4+4 PIN CONNECTORS : 1
SATA CONNECTORS : 5
PERIPHERAL 4-PIN CONNECTORS : 3
PCI-E 6+2 PIN CONNECTORS : 2
SERIE : Elite Series
80 PLUS : Standard
MODULAR : Non Modular
WATTAGE : 500 to 750W
