Model Number
MCB-D500D-KGNN-S01, MCB-D500D-KGNN-S00, MCB-D500D-WGNN-S01, MCB-D500D-WGNN-S00
Series
MasterBox Series
Size
Mid Tower
Available Color(s)
Black, White
Materials
Steel, Plastic, Tempered Glass, Mesh
Dimensions (L x W x H)
493 x 217 x 469mm (incl. Protrusions), 429.5 x 205x 447mm (excl. Protrusions)
Weight
6.95 kg
Motherboard Support
Mini ITX, Micro ATX, ATX, SSI CEB, E-ATX*, (*support for up to 12" x 10.7", will limit cable management features)
Expansion Slots
7
5.25" Drive Bays
N/A
2.5" / 3.5" Drive Bays (combo)
2
2.5" Drive Bays
4 (2+2 combo)
I/O Panel
2x USB 3.2 Gen 1 (formerly USB 3.0), 1x 3.5mm Audio Jack, 1x 3.5mm Mic Jack, 1x ARGB Controller (only for the S01 versions), 1x ARGB 2-to-3 splitter
Pre-installed Fans - Top
N/A
Pre-installed Fans - Front
3x 120mm ARGB Fans
Pre-installed Fans - Rear
N/A
Fan Support - Top
3x 120mm, 2x 140mm
Fan Support - Front
3x 120mm, 2x 140mm
Fan Support - Rear
1x 120mm
Radiator Support - Top
120mm, 240mm, 360mm, (44mm max motherboard component height)
Radiator Support - Front
120mm, 140mm, 240mm, 280mm, 360mm
Radiator Support - Rear
120mm
Clearance - CPU Cooler
165mm/6.49"
Clearance - PSU
180mm/7.08", 295mm/11.61" (w/ HDD cage removed)
Clearance - GFX
410mm/16.1"
Cable Routing
19mm/0.74"
Dust Filters
Top, Bottom, Front
Power Supply Support
Bottom mount, ATX
