The ASUS Prime AP201 is a stylish 33-liter MicroATX case with tool-free side panels and a quasi-filter mesh, with support for 360 mm coolers, graphics cards up to 338 mm long, and standard ATX PSUs.


• Quasi-Filter Mesh Panels: A mesh design comprised of over 57,000 precision-machined 1.5mm holes increases airflow and provides a compelling view of the components within your build.
• Optimized for Cooling: With support for 280 and 360mm radiators and up to six fans, the AP201 is primed to deal with the thermal onslaught of high-performance hardware.
• Industry-Leading Spatial Efficiency: Despite a 33L footprint, the AP201 supports ATX PSUs up to 180 mm long, graphics cards up to 338 mm long, custom liquid cooling, and various storage devices.
• Tool-Free Side Panels: A simple yet secure clip mechanism allows chassis side panels to be easily removed and resistant to accidental dislodging.
• Sizeable Cable-Management: The AP201 features an extended motherboard tray with strategically placed cutouts and a 32 mm gap to tuck cables out of sight.
• Front Panel USB Type-C® Support: The front panel of the AP201 features a USB 3.2 Gen 2 Type-C port, so users can enjoy transfer speeds of up to 10 Gbps.

Case Size: Small Tower

Motherboard Support:
Micro-ATX
Mini-ITX

Drive Bays:
1 x 2.5" Bay
3 x 2.5"/3.5" Combo Bay

Expansion Slots: 4

Front I/O Port:
1 x Headphone
1 x Microphone
2 x USB 3.2 Gen1
1 x USB 3.2 Gen2 Type C

Radiator Support (Top):
120 mm
140 mm
240 mm
280 mm
360 mm

Radiator Support (Rear): 120 mm

Cooling Support (Top):
3 x 120 mm
2 x 140 mm

Cooling Support (Rear): 1 x 120 mm

Pre-installed Fans (Front): None

Pre-installed Fans (Rear): 1 x 120 mm

Maximum CPU Cooler Height: 170 mm

Maximum GPU Length: 338 mm

Maximum PSU Length: 140-180 mm

Removable Dust Filters: Bottom

Maximum Cable Management Space: 32 mm

Dimensions: 205 x 350 x 460 mm

Weight: 5.8 Kg
