CPU
- Intel® Socket LGA1700 for 12th Gen Intel® Core™, Pentium® Gold and Celeron® Processors

Chipset
- Intel Z690

Memory
4 x DIMM, Max. 6400+(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800MHz Non-ECC, Un-buffered Memory*

Graphics
- 2 x Intel® Thunderbolt™ 4 ports (USB Type-C®) support DisplayPort 1.4 and Thunderbolt™ video outputs
* Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates.

Expansion Slots
- Intel® 12th Gen Processors*
* 2 x PCIe 5.0 x16 slots (supports x16 or x8/x8 modes)**
- Intel® Z690 Chipset
* 1 x PCIe 3.0 x1 slot

Storage
- Supports 5 x M.2 slots and 6 x SATA 6Gb/s ports
- Intel®12th Gen Processors*
* M.2_1 slot (Key M), type 2242/2260/2280/22110***
* M.2_2 slot (Key M), type 2280
- Intel® Z690 Chipset**
* M.2_3 slot (Key M), type 2280 (supports PCIe 4.0 x4 & SATA modes)
* DIMM.2_1 slot (Key M) via ROG DIMM.2, type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)
* DIMM.2_2 slot (Key M) via ROG DIMM.2, type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)
* 6 x SATA 6Gb/s ports*****

Ethernet
- 1 x Intel® 2.5Gb Ethernet
- 1 x Marvell® 10Gb Ethernet

Wireless & Bluetooth
- Intel® Wi-Fi 6E
- 2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax)
- Supports 2.4/5/6GHz frequency band*
- Bluetooth v5.2
* WiFi 6E 6GHz regulatory may vary between countries, and function will be ready in Windows 11 or later.

Form Factor
- EATX
- 30.5cm x 27.7cm
