Power Supply ASUS PRIME AP 750G 750W GOLD
90YE00U1-B0NA00
--------------------

Specifications

Model : AP-750G
Intel Form Factor : ATX12V
PFC Type : Active PFC
ATX 3.0 : Yes
Dimensions : 150 x 150 x 86 mm
Efficiency : 80Plus Gold
Protection Features : OPP/OVP/UVP/SCP/OCP/OTP
Hazardous Materials : ROHS
AC Input Range : 100-240Vac
DC Output Voltage : +3.3V +5V +12V -12V +5Vsb
Maximum Load : 20A20A62A 0.3A 2.5A
Combined Load : 110W 110W 744W 3.6W 12.5W
Total Output : 750W

Cable Connectors :
- MB 24/20-pin x 1
- CPU 4+4-pin x 2
- PCI-E 16-pin x 1 (both PSU & connector side)
- PCI-E 8-pin x 3
- SATA x 5
- PERIPHERAL x 3

Package Contents :
- Power Cord x 1
- Motherboard Power Cable x 1 (610mm)
- CPU Cable x 2 (650mm)
- PCI-E Gen 5 16-pin Cable x 1 (675mm)
- PCI-E (16-pin to 8-pin-8-pin) Cable x1 (675mm)
- PCI-E 1-to-1 Cable x 1 (675mm)
- SATA 1-to-2 Cable x 1 (400+120mm)
- SATA 1-to-3 Cable x 1 (400+120+120mm)
- Peripheral 1-to-3 Cable x 1 (400+150+150mm)
- User Manual x 1

Weight : 1.466 kg (single PSU)
0dB Technology : No

WARRANTY 8 YEAR
